Automatic Linear Capping Machine Details
Automatic Linear capping machine is used to apply the screw cap on bottle. This is a linear motion screw capping machine. Technogen Enterprise is manufacturer, supplier and exporter of vast range of Automatic Linear capping machine. Linear capping Machine is used for capping of round, flat, irregular shapes bottle with the speed of 100 bottles per minute. The Main advantage of the inline linear capping machine is the least use of the change part where change in diameter or height of the bottle. The linear capping machine uses special bottle griping bottle assembly to hold the bottle during capping process. Further capping is done using the 3 sets of the cap tightening disc.
Automatic Linear Capping Machine applies in Pharmaceuticals, Distilleries & Breweries, Cosmetics & Toiletries, Lube & Edible Oil, Pesticides, Food & Ancillaries & Confectionary.
SALIENT FEATURE:
- Compact and CGMP Model
- We fabricate machine using a fine grade of Stainless-Steel material.
- Linear design makes our this capping machine suitable for various threaded caps & bottles with good adaptability, used for screwing jar cap, plastic threaded caps, pump spray caps, metal caps.
- Various types of Cap feeding choice likewise Cap feeder elevator, vibrator.
- State-of-the-art bottle gripping assembly.
- 3 sets of tightening discs include the first rotating & re-rotating degree of moment can be adjusted & make sure perfect tightening.
- Tightening disc has inbuilt clutch to avoid the cap over-rotating.
- Tool less adjusts for change in bottle size.
- No / least change part required for a change in container / bottle size
- Lowest power consumption among industries.
- maintenance free machine.
- Variable frequency drive for speed variation.
Safety Features of Automatic Linear Capping Machine:
- No Bottle–No Cap mechanism
- No Cap–Cap Feeder on.
ADD-ON FEATURE:
- PLC – HMI Interface
- Toughened Glass / Polycarbonate / Acrylic Safety Cabinet with door interlock.
Technical Specification of Automatic Linear Capping Machine:
| Machine Name | Automatic Linear Capping Machine |
| Model No | TGLC-100 |
| Direction | Left to Right |
| Automation Grade | Automatic |
| Machine Usage application | Apply Screw Cap on the Glass, Plastic, HDPE, LDPE and Pet Bottle. |
| Brand | Technogen Enterprise |
| Operating direction | Left to write |
| Machine production Speed | · 100 Bottle per minute depending upon the Cap as well as bottle diameter. |
| Speed Variation | Through Variable Frequency Drive |
| Cap Feeding | · By Cap Feeder Elevator or Cap feeder vibrator |
| Bottle holding | · Through Belt assembly |
| Number of Cap Tightening disc | 6 Nos (3 set of cap tightening device) |
| Container Diameter Range (mm) | 50 mm to 200 mm |
| Container Height Range (mm) | 75 mm to 400 mm |
| Cap Diameter Range (mm) | 18 mm to 120 mm |
| Conveyor Height (mm) | 850 ± 50 mm from Datum |
| Power Consumption | 2 KW |
| Electrical Connection | 440 V ,3 Phase (4 Wire System ) 50 HZ |
| Control Panel | Stainless Steel 304 make Bottom Pedant type Machine mounted Panel |
| Control Panel | Stainless Steel 304 make Bottom Pedant type Machine mounted Panel |
| Production Counter | 6 digit counter inbuilt |
| Height of Conveyor from Datum | Adjustable from 800 to 850 mm |
| Dimension | 1830 (L) X 1230 (W) X 1600 (H)mm |
| Net Weight of Machine
(KG) |
250 |
| Gross Weight of Machine (KG) | 475 |
| Warranty of Machine | 1 Year from date of dispatch |
| Country of Origin | India |
RELEVANT ADDITIONAL TRADE DETAILS:
| Minimum Order Quantity of Machine | 1 Number |
| Production Capacity of Automatic Linear Capping Machine | 5 Machines / Month |
| Product ordering Code | TGLC-100 |
| Delivery Time | 4 to 5 weeks |
| Machine Packaging Details | ISBM-15 compliant Sea worthy Packaging |
| Nearest Seaport | Mudra, Gujarat, India |
| Payment Mode | In International Trade – By T/T , By L/C |
